LevelOne 48V DC Industrial Power Supply, 120W, DIN-Rail, PoE Ready
€93,97
Taxes included.
30-day returns
On request, subject to conditions. Check the return policy and exceptions.
Need help before buying?
Contact our team for product questions or help with your order.
The LevelOne POW-4841 is a 48V DC industrial power supply delivering 120W on a standard 35 mm DIN rail. Universal AC input from 90V to 264V works globally, and the 48V output suits PoE switches, injectors, and telecom-grade equipment.
Fanless free-air convection cooling means silent operation and no fan to fail. Full protection suite — short-circuit, overload, over-voltage, and over-temperature — keeps the supply and downstream loads safe when a fault occurs in the field.
Built for industrial control cabinets, factory automation lines, semiconductor fabrication tooling, and electro-mechanical apparatus where 120W of clean 48V DC is needed in a compact DIN-rail format.
Fanless free-air convection cooling means silent operation and no fan to fail. Full protection suite — short-circuit, overload, over-voltage, and over-temperature — keeps the supply and downstream loads safe when a fault occurs in the field.
Built for industrial control cabinets, factory automation lines, semiconductor fabrication tooling, and electro-mechanical apparatus where 120W of clean 48V DC is needed in a compact DIN-rail format.
Specifications
Power
| Total power | 120 W |
| AC input voltage | 90 - 264 V |
| Power protection features | Over voltage, Overload, Short circuit |
Performance
| Mean time between failures (MTBF) | 474600 h |
Design
| Product colour | Mint colour, Silver |
| LED indicators | Yes |
Operational conditions
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 20 - 95% |
| Storage relative humidity (H-H) | 10 - 90% |
Safety regulation & standards
| Safety | UL508, TUV EN60950-1, EAC TP TC 004, BSMI CNS14336-1 approved;(meet EN60204-1) |
Weight & dimensions
| Width | 125.2 mm |
| Depth | 113.5 mm |
| Height | 40 mm |
| Weight | 600 g |
Packaging data
| Package width | 125.2 mm |
| Package depth | 113.5 mm |
| Package height | 40 mm |
| Package weight | 600 g |
Logistics data
| Harmonized System (HS) code | 84733020 |
| Country of origin | China |
Other features
| Output voltage note | 48V DC |
