ATEN 8 Port True 4K HDMI Switch
€384,17
Taxes included.
30-day returns
On request, subject to conditions. Check the return policy and exceptions.
Need help before buying?
Contact our team for product questions or help with your order.
The ATEN VS0801HB is designed for applications that require the routing of 8 sources to one compatible display device. It supports video resolutions up to True 4K (4096 x 2160 @ 60Hz 4:4:4), data rates up to 18 Gbps, 3D, Deep Color up to 12-bit, and HD lossless audio formats. The VS0801HB features Auto Switching modes for auto port selection. Multiple convenient control options include front panel pushbuttons, bi-directional RS-232, IR, and auto switch, allowing for easy integration.
1x VS0801HB 8-port True 4K HDMI Switch
1x 2XRT-0007G IR Remote Control Unit
1x 2XRT-0003G IR Receiver Cable
1x 0AD6-1F05-26EG Power Adapter
1x Rack Mounting Kit
1x User Instructions
1x VS0801HB 8-port True 4K HDMI Switch
1x 2XRT-0007G IR Remote Control Unit
1x 2XRT-0003G IR Receiver Cable
1x 0AD6-1F05-26EG Power Adapter
1x Rack Mounting Kit
1x User Instructions
Specifications
Ports & interfaces
| Video port type | HDMI |
| HDMI ports quantity | 8 |
| HDMI version | 2.0 |
| HDMI in | 8 |
| Number of HDMI outputs | 1 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
Features
| Material | Metal |
| Product colour | Black |
| Consumer Electronics Control (CEC) support | Yes |
| HDCP | Yes |
| Maximum refresh rate | 60 Hz |
| Maximum operating distance | 3 m |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 |
| Bandwidth | 18 Gbit/s |
| Bandwidth | 600 MHz |
| Maximum resolution | 4096 x 2160 pixels |
| 3D | Yes |
| HD type | 4K Ultra HD |
| Input impedance | 100 Ω |
| Output impedance | 100 Ω |
| HDCP version | 2.2 |
Power
| AC adapter input voltage | 5.3 V |
| Power consumption (typical) | 3.73 W |
Weight & dimensions
| Width | 158.3 mm |
| Depth | 437.2 mm |
| Height | 44 mm |
| Weight | 2.42 kg |
Packaging data
| Package width | 116 mm |
| Package depth | 540 mm |
| Package height | 233 mm |
| Package weight | 2.87 kg |
Packaging content
| Mounting kit | Yes |
| AC adapter included | Yes |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Logistics data
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 375 mm |
| Master (outer) case length | 565 mm |
| Master (outer) case height | 258 mm |
| Master (outer) case gross weight | 9.5 kg |
| Products per master (outer) case | 3 pc(s) |
| Master (outer) case net weight | 7.26 kg |
